Boas!
Recentemente adquiri uma EasyHan ao @nikito7 e apesar de funcionar perfeitamente “out of the box” com Tasmota decidi “complicar” e flashar com ESPHome
Com ESPHome é, na minha opinião, mais simples de manter e a integração com HA é nativa, sem recurso a MQTT.
Para o fazerem podem usar o yaml disponivel aqui (monofasico).
Caso não saibam como migrar de Tasmota para ESPHome, as instruções estão disponiveis aqui.
Apesar do yaml do @nikito7 funcionar perfeitamente, decidi “simplificar” por retirar o que não precisava (Exportação, Relogio, LP etc) e aumentar o refresh rate ao máximo (neste momento 5s).
Adicionei também uma entidade para o Tempo de Disparo que no meu caso é muito importante. Claro que já o podiam criar como template no HA mas assim é muito mais facil.
Segue o meu yaml atual (WIP)
substitutions:
dev: EB1
name: easyhan
friendly_name: EasyHAN
# interval:
# - interval: 9s
# then:
# - lambda: |-
# if (id(edpbox_polling).state) {
# id(edpbox).update();
# }
esphome:
name: ${name}
friendly_name: ${friendly_name}
platform: ESP8266
board: esp07s # 4MB
# on_boot:
# priority: -500
# then:
# - delay: 30s
# - switch.turn_on: edpbox_polling
wifi:
output_power: 15db
#domain: .lan
use_address: 192.168.1.122
# fix ota dns error
reboot_timeout: 10min
domain: .lan
ssid: !secret wifi_ssid
password: !secret wifi_password
# Enable fallback hotspot (captive portal) in case wifi connection fails
ap:
ssid: "Easyhan Fallback Hotspot"
password: "xxx"
captive_portal:
web_server:
local: true
logger:
level: verbose
# baud_rate: 0
api:
reboot_timeout: 45min
encryption:
key: "xxx"
ota:
password: "xxx"
time:
- platform: homeassistant
id: esptime
button:
- platform: restart
name: "${dev} ESP Restart"
device_class: restart
entity_category: diagnostic
# switch:
# - platform: template
# name: "${dev} ESP Polling"
# id: "edpbox_polling"
# optimistic: yes
# device_class: switch
# entity_category: diagnostic
uart:
# esp32 19/18
# esp8266 3/1
# tfreire 14/5
id: modbus_serial
rx_pin: 3
tx_pin: 1
baud_rate: 9600
stop_bits: 1
#stop_bits: 2 # ziv
modbus:
#flow_control_pin: 5
id: modbus1
uart_id: modbus_serial
send_wait_time: 350ms
modbus_controller:
- id: edpbox
update_interval: 5s
address: 0x1
command_throttle: 150ms
setup_priority: -10
offline_skip_updates: 20
sensor:
# - platform: adc
# # internal VCC esp8266 only
# # pin: VCC
# pin: A0
# filters:
# - multiply: 6.3
# name: "${dev} Adc Addon"
# accuracy_decimals: 3
# device_class: voltage
# state_class: measurement
# update_interval: 11s
# entity_category: diagnostic
- platform: template
name: "${dev} ESP Free Heap"
lambda: |-
int heap = ESP.getFreeHeap();
return heap / 1024.0;
unit_of_measurement: "kB"
icon: mdi:chip
entity_category: diagnostic
- platform: wifi_signal
name: "${dev} ESP Signal"
unit_of_measurement: "dB"
entity_category: diagnostic
device_class: signal_strength
- platform: uptime
name: "${dev} ESP Uptime"
filters:
- lambda: return x/3600;
unit_of_measurement: "h"
accuracy_decimals: 1
device_class: duration
entity_category: diagnostic
### ### ###
### Voltage & Current ###
- platform: modbus_controller
name: "${dev} Voltage L1"
address: 0x006C
unit_of_measurement: "V"
register_type: read
value_type: U_WORD
accuracy_decimals: 1
filters:
- multiply: 0.1
device_class: voltage
- platform: modbus_controller
name: "${dev} Current L1"
address: 0x006D
unit_of_measurement: "A"
register_type: read
value_type: U_WORD
accuracy_decimals: 1
filters:
- multiply: 0.1
device_class: current
### Active Power & Power Factor ###
- platform: modbus_controller
name: "${dev} Active Power Import"
id: power_import
address: 0x0079
register_type: read
value_type: U_DWORD
register_count: 1
response_size: 4
accuracy_decimals: 0
device_class: power
unit_of_measurement: "W"
on_value:
then:
component.update: icp_fire_time
# - platform: modbus_controller
# name: "${dev} Active Power Export"
# address: 0x007A
# register_type: read
# value_type: U_DWORD
# register_count: 1
# response_size: 4
# accuracy_decimals: 0
# device_class: power
# unit_of_measurement: "W"
- platform: modbus_controller
name: "${dev} Power Factor"
id: power_factor
address: 0x007B
unit_of_measurement: ""
register_type: read
value_type: U_WORD
accuracy_decimals: 3
filters:
- multiply: 0.001
device_class: power_factor
on_value:
then:
component.update: icp_fire_time
### Frequency ###
# - platform: modbus_controller
# name: "${dev} Frequency"
# address: 0x007F
# unit_of_measurement: "Hz"
# register_type: read
# value_type: U_WORD
# accuracy_decimals: 1
# filters:
# - multiply: 0.1
# icon: "mdi:pulse"
### Total Energy Tariffs ###
- platform: modbus_controller
name: "${dev} T1 Vazio"
address: 0x0026
register_type: read
value_type: U_DWORD
register_count: 1
response_size: 4
accuracy_decimals: 3
filters:
- multiply: 0.001
unit_of_measurement: "kWh"
state_class: total_increasing
device_class: energy
skip_updates: 2
- platform: modbus_controller
name: "${dev} T2 Ponta"
address: 0x0027
register_type: read
value_type: U_DWORD
register_count: 1
response_size: 4
accuracy_decimals: 3
filters:
- multiply: 0.001
unit_of_measurement: "kWh"
state_class: total_increasing
device_class: energy
- platform: modbus_controller
name: "${dev} T3 Cheias"
address: 0x0028
register_type: read
value_type: U_DWORD
register_count: 1
response_size: 4
accuracy_decimals: 3
filters:
- multiply: 0.001
unit_of_measurement: "kWh"
state_class: total_increasing
device_class: energy
### Total Energy ###
- platform: modbus_controller
name: "${dev} Import"
address: 0x0016
register_type: read
value_type: U_DWORD
register_count: 1
response_size: 4
accuracy_decimals: 3
filters:
- multiply: 0.001
unit_of_measurement: "kWh"
state_class: total_increasing
device_class: energy
# - platform: modbus_controller
# name: "${dev} Export"
# address: 0x0017
# register_type: read
# value_type: U_DWORD
# register_count: 1
# response_size: 4
# accuracy_decimals: 3
# filters:
# - multiply: 0.001
# unit_of_measurement: "kWh"
# state_class: total_increasing
# device_class: energy
### Contract ###
- platform: modbus_controller
name: "${dev} Contract T1"
id: contract_t1
address: 0x000C
force_new_range: true
register_type: read
value_type: U_DWORD
register_count: 1
response_size: 4
accuracy_decimals: 2
filters:
- multiply: 0.001
unit_of_measurement: "kVA"
state_class: measurement
##ICP Fire Timre
- platform: template
name: "${dev} ICP Fire Time"
id: icp_fire_time
icon: mdi:clock
unit_of_measurement: "s"
device_class: duration
accuracy_decimals: 0
#update_interval: 2s
lambda: |-
int watts = int(id(power_import).state);
ESP_LOGD("main", "Watts: %d", watts);
float pf = float(id(power_factor).state);
ESP_LOGD("main", "pf: %f", pf);
float potencia_inst = (watts/pf);
ESP_LOGD("main", "potencia_inst: %f", potencia_inst);
float potencia_max_kva = float(id(contract_t1).state)*1000;
ESP_LOGD("main", "potencia_max_kva: %f", potencia_max_kva);
int q_factor = 50;
ESP_LOGD("main", "q_factor: %d", q_factor);
float k_factor = (120.0/100.0);
ESP_LOGD("main", "k_factor: %f", k_factor);
int x = round(q_factor/((potencia_inst/potencia_max_kva)-k_factor));
ESP_LOGD("main", "x: %d", x);
if(x > 0 and x < 900) {
return x;
} else {
return 0;
}
### ### ###
text_sensor:
# - platform: template
# name: "${dev} ESP Clock"
# id: esp_clock
# icon: mdi:clock
# entity_category: diagnostic
###
# - platform: modbus_controller
# name: "${dev} Clock"
# register_type: read
# address: 0x0001
# register_count: 1
# response_size: 12
# raw_encode: HEXBYTES
# icon: mdi:clock
# lambda: |-
# uint8_t hh=0,mm=0,ss=0;
# hh = esphome::modbus_controller::byte_from_hex_str(x,5);
# mm = esphome::modbus_controller::byte_from_hex_str(x,6);
# ss = esphome::modbus_controller::byte_from_hex_str(x,7);
# char buffer[20];
# sprintf(buffer,"%02d:%02d:%02d",hh,mm,ss);
# return {buffer};
# on_value:
# - then:
# - lambda: |-
# char str[25];
# time_t currTime = id(esptime).now().timestamp;
# strftime(str, sizeof(str), "%H:%M:%S", localtime(&currTime));
# id(esp_clock).publish_state({str});
###
- platform: modbus_controller
name: "${dev} Tariff"
register_type: read
address: 0x000B
register_count: 1
response_size: 2
raw_encode: COMMA
icon: mdi:counter
lambda: |-
auto z = "Null";
if (x == "1,0") z = "Vazio";
else if (x == "2,0") z = "Ponta";
else if (x == "3,0") z = "Cheias";
return {z};
#######
# eof #
#######
Não sou de todo expert na materia mas creio que com modbus é impossivel ter dados em “real time” e vamos ter sempre de ter um polling rate definido?
🫣
